3m (10ft) 200G QSFP56 InfiniBand HDR Passive Direct Attach Copper Twinax Cable for Mellanox

Click to open expanded view

Global Local Service

Lifetime Technical Support

Mellanox MCP1650-H003E26 Compatible DAC 3m (10ft) 200Gb/s QSFP56 to QSFP56 IB HDR Passive Direct Attach Copper Twinax Cable

Name: Mellanox MCP1650-H003E26 Compatible DAC 3m (10ft) 200Gb/s QSFP56 to QSFP56 IB HDR Passive Direct Attach Copper Twinax Cable
Brand: Naddod
SKU: 32658
Price: 106.00 USD
Availability: InStock
Rating: 4.9 (3 reviews)

#32658

Model: Q56-200G-CU3H

Sold: 184

In Stock : 346

Shipping Today

$ 106

Request Free Samples

Brand:

NADDOD (InfiniBand)

Length:

1m (3ft)

2m (7ft)

3m (10ft)

1m (3ft)

2m (7ft)

3m (10ft)

Item Spotlights

Up to 200Gb/s data rate.
Max.power consumption<0.1W.
Minimum bend radius 35mm for flexible routing.
Low bit error rate and latency for best InfiniBand HDR end-to-end performance.
Professional compatibility and parameter test reports provided.
Hot pluggable QSFP28 MSA, SFF-8636, SFF-8665 and RoHS environmental standard compliant.
Higher network efficiency for data center server and storage connectivity.
Fix bit errors throughout the network and reduce the overhead for data retransmission.
30-Day Free Return, 3-Year Free Exchange, 3-Year Warranty.

Mellanox MCP1650-H003E26 Compatible DAC 3m (10ft) 200Gb/s QSFP56 to QSFP56 IB HDR Passive Direct Attach Copper Twinax Cable

Free Worldwide Shipping on Orders over $ 99

Description

Connectivity Solutions

Highlights

Questions & Answers

Resources

$ 106

Description

Connectivity Solutions

Highlights

Questions & Answers

Resources

NVIDIA/Mellanox® MCP1650-H003E26 Compatible 3m (10ft) HDR 200Gb/s QSFP56 Direct Attach Passive Copper Cable (PVC, 26AWG, Black Pulltab)

NVIDIA/Mellanox® MCP1650-H0xxEyy DAC cables are high speed, cost-effective alternatives to fiber optics in 200Gb/s InfiniBand HDR applications. NADDOD offers Mellanox MCP1650-H003E26 Compatible 3m (10ft) 200GBASE QSFP56 to QSFP56 direct attach copper cable (DAC cable) for QM8700/QM8790, MCX653106A-HDAT-SP/MCX653105A-HDAT-SP/MCX653106A-ECAT-SP/MCX653105A-ECAT-SP. It's designed for use in 200GBASE Ethernet and InfiniBnad HDR system to provide power-efficient connectivity for short distance interconnects. It enables higher port bandwidth, density and configurability of reducing power requirement in the data centers and HPC (High Performance Computing ). NADDOD 200GBase-CU QSFP56 DAC cables compliant with IEEE 802.3cd and QSFP MSA Compliant, be widely used in 200G Ethernet, InfiniBand HDR, data center, HPC and storage area network.

Specifications

Compatible

MCP1650-H003E26

Modulation Format

4x 50Gb/s PAM4

Product Type

Q56-200G-CU3H

Vendor Name

NADDOD

Connector Type

Q56 to QSFP56

Max Data Rate

200Gb/s

Max Data Rate

200Gbps-2x100Gbps

Minimum Bend Radius

35mm

Wire AWG

26AWG

Cable Length

Jacket Material

PVC(OFNR)

Bit Error Rate (BER)

Better Than 1E-15

Power Supply

Single 3.3V

Power Consumption

4.35W Power Dissipation

Hot pluggable

Supported

Programmable Rx output amplitude and pre-emphasis

Supported

Application

200G InfiniBand, 200G Ethernet, HPC, Datacenter

Commercial Temperature Range

0~70°C

Protocols

IEEE 802.3bj，IEEE 802.3cd，SFF-8636，SFF-8665, IBTA InfiniBand HDR, RoHS

Connectivity Solutions

ID	Part Number	Description	Unit Price
32658	Q56-200G-CU3H	3m (10ft) 200G QSFP56 InfiniBand HDR Passive Direct Attach Copper Twinax Cable for Mellanox	$ 106
32645	Q2Q56-200G-A1H	Mellanox MFS1S50-H001E/MFS1S50-H001V Compatible 1m (3ft) 200G QSFP56 to 2X100G QSFP56 Breakout Active Optical Cable for InfiniBand HDR	$ 719.00
/	MQM8700-HS2F	Mellanox Quantum™ HDR InfiniBand Switch, 40 QSFP56 ports, 2 Power Supplies (AC), x86 dual core, standard depth, P2C airflow, Rail Kit	/
/	MQM8790-HS2F	Mellanox Quantum™ HDR InfiniBand Switch, 40 QSFP56 ports, 2 Power Supplies (AC), unmanaged, standard depth, P2C airflow, Rail Kit	/
/	MCX654106A-ECAT	ConnectX®-6 VPI adapter card, 100Gb/s (HDR100, EDR InfiniBand and 100GbE), dual-port QSFP56, Socket Direct 2x PCIe 3.0/4.0 x16, tall bracket	/
/	MCX653436A-HDAI	ConnectX®-6 VPI adapter card, 200Gb/s (HDR IB and 200GbE) for OCP 3.0, with host management, Dual-port QSFP56, PCIe4.0 x16, Internal Lock	/

Product Highlights

Unique advantages of NADDOD 200G InfiniBand HDR direct attach copper

NADDOD's 200G InfiniBand HDR QSFP56 DAC passive copper cable based on 4X25G/4X28G or 4*50G/4*56G (PAM-4) structure, can well meet the needs of next-generation 2X100G switches, servers, routers and other product applications, suitable for a variety of high-speed use scenarios, ultimizing optimized design to reduce crosstalk and insertion loss, with excellent signal integrity, fully compliant with next-generation Ethernet and InfiniBand standards.

What is InfiniBand?

InfiniBand, supported by all major OEM server vendors, is a high-performance, versatile network architecture based on a switched fabric. As a way to extend and create the next generation of server I/O interconnect standards. It has become a leading standard for high performance computing.

Six professional transceiver performance tests

NADDOD has a full range of professional testing equipments for testing various parameters of products to ensure high performance and quality of optical transmission stability.

Quality Certification

What We Supply

Questions & Answers

Is there any 200G 3m IB DAC MCP1650-H003E26 in stock?

Yes, of course, you can check the stock info below the product title. Our 1m-30m 200G IB cables are in large stock, which support same-day shipping after passing full test process. For other meters not shown, you can click contact us/quote/need help for inquiry. As you may know, the lead time of NVIDIA original IB cables MCP1650-H003E26 is 6 to 8 weeks, while NADDOD can support ship within 1 week and even for your special customized requirements, our lead time is only 2 weeks.

What's the difference between QM8700 and QM8790 switches? Whether there is a difference in the selection of the cables?

There is no difference in function and performance between QM8700 and QM8790. QM8700 is managed, and QM8790 is unmanaged (out-of-band management). NADDOD can provide 200G IB AOC and DAC cables that can be used with the two switches.

Are InfiniBand cables generally referred to AOC?

No, there are two kinds of InfiniBand cables: DAC(copper) and AOC (optical). NADDOD can provide InfiniBand FDR, EDR, HDR DAC, and AOC cables at super affordable prices and large stock.

We have some QM8700 200G switches connected with the original IB cables MCP1650-H003E26 , whether there'll be any incompatibility problem if we use them with your cables?

NADDOD IB cables are perfect alternative option for Mellanox MCP1650-H003E26, beyond IBTA industry bit-error-rate (BER) standards. We can provide the technical test report for your specified original device environment. You can also check our practical cases/solutions, which had proved that our IB products can reach even exceed the performance and quality of the originals.

Could you please provide two real pictures of a 10m 200G EDR AOC for me, with the outer label showing the length 10m?

Okay, please check the picture below. The outer jacket materials of all our InfiniBand cables are LSZH (Low Smoke Zero Halogen) and certified by UL OFNR (fire rating level). Our cable levels are the same as NVIDIA Mellanox LinkX InfiniBand Cables MCP1650-H003E26.

What's the AWG (American Wire Gauge) of the InfiniBand Mellanox MCP1650-H003E26 HDR 200Gb/s QSFP56 Direct Attach Passive Copper Cable? 26AWG or 30AWG?

Mellanox official standard for MCP1650-H003E26 passive copper cable is 26AWG. For Mellanox Passive Copper cable, less than 2 meters (0.5/1.0/1.5 meter) , it is 30AWG. NADDOD InfiniBand AOC/DAC cable's AWG standard is completely same with Mellanox standard, please rest assured to buy.

Whether the InfiniBand cables MCP1650-H003E26 can be used on Ethernet switches?

Yes, InfiniBand cables MCP1650-H003E26 can be used for both IB and Ethernet, but Ethernet cables can only be used for Ethernet. NADDOD provides both high cost-effective IB and Ethernet cables for your options.

If hypothetically we had a problem where we don’t know if the issue is with the NADDOD cables or with the Mellanox switches, or maybe Mellanox switch failure due to cable's problem, would you provide us technical support？

Of course. No matter what problem you have, you can just contact us directly. NADDOD will provide technical support: including switch and network configuration services to help you find out and solve problems.And please make sure: AOC/DAC cables or transceivers are networking interconnection accessories, which essentially are just a connection of signal transmission and don't cause any hardware or software problems to the original devices. NADDOD Test Center recreates a 100% original environment for testing all parts of our IB products to provide customers the highest quality and performance.

Where can I download FW for QM8700 IB switch?

QM8700 do not have FW file. Because managed systems do not require Firmware updating. Firmware updating is done through the MLNX-OS management software. You can download the firmware updating file in the Resources section of the QM8790 listing, or click here for other QM87XX series switches firmware updating user manual.

Resources

Q56-200G-DAC Datasheet
