NADDOD 1.6T OSFP DR8 InfiniBand XDR features Marvell 5nm DSP, single-mode for 500m transmission distance for cost-effective alternative solution in HPC and AIDC.

NADDOD 800G OSFP InfiniBand XDR transceivers come in OSFP form factor shape, used over single-mode fiber as a media. The product portfolio comprehends 800G DR4(500m). It is used to link the Quantum-X800 QM3x00 switches using Twin-port OSFP 2x800Gb/s transceivers to the dual 800Gb/s ConnectX-8 mezzanine card located internally in the GB200-based, liquid-cooled system with high performance.

NADDOD 800G InfiniBand NDR modules come in OSFP form factor shape, used over single-mode and multi-mode fiber as a media. The product portfolio comprehends 800G 2×SR4, 2×DR4 and 2×FR4. Interconnection distances range from 30m to 2km. NADDOD 800G 2×SR4 are embedded with Broadcom VCSEL and Broadcom DSP for delivering high-quality signal transmission. NADDOD 800G 2×DR4 and 2×FR4 can be compatible with low-cost DAC by adjusting the layout of the data center and providing unparalleled bandwidth and efficiency.

NADDOD Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP InfiniBand NDR passive and active direct attached copper cables(DAC) assembly can offer powerful performance, which is suitable for short distance data transmission. NADDOD 800G Twinax cables are the lowest-cost and high-speed links available due to their advanced design， containing eight high-speed electrical copper pairs, each operating at data rates of up to 100Gb/s. It is commonly used for linking together two twin-port, OSFP-based Quantum-2 InfiniBand switches to each other.

NADDOD 800G breakout InfiniBand NDR DAC includes 800G Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP InfiniBand NDR passive and active copper splitter cables. It provides connectivity between system units with an 800Gb/s OSFP port on one side and two 400Gb/s OSFP ports on the other. It is a high-quality, cost-effective alternative to fiber optics in 800Gb/s to 400Gb/s applications for high-speed, efficient, and sustainable network connectivity.

NADDOD 800G breakout InfiniBand NDR DAC comprehends Twin-port 2x400G OSFP to 4x200Gb/s OSFP InfiniBand NDR passive and active copper splitter cables. It provides connectivity between system units with an 800Gb/s OSFP port on one side and four 200Gb/s OSFP ports on the other. It is designed to provide ultra-low latency, ensuring real-time performance for the most demanding applications.

NADDOD 400G InfiniBand NDR modules come in OSFP, QSFP112 form factor shape for multimode, and single mode fiber as a media. The product portfolio comprehends 400G OSFP/QSFP112 SR4 and 400G OSFP DR4. The transmission distances are from 50 to 100 meters. 400G IB modules are often paired with 800G transceivers, ensuring seamless connectivity and interoperability between 400G and 800G modules by using compatible fiber cables. NADDOD 400G IB transceivers offer higher speeds and greater efficiency for bandwidth-intensive applications.

NADDOD 400G breakout InfiniBand NDR active optical cables(AOC) provide connectivity between system units with an OSFP 400Gb/s connector on one side and two separate QSFP56 200Gb/s connectors on the other, such as a switch and two servers. NADDOD 400G AOC supports high-speed data transmission at rates up to 400Gbps with a smaller size and lightweight to meet the demand for high bandwidth, and cabling in data centers and high-performance computing environments.

NADDOD 400G breakout InfiniBand NDR direct attached copper cables(DAC) have an 8-channel twin-port OSFP end using a finned top form factor for use in Quantum-2 and Spectrum-4 switch cages. It provides connectivity between system units with an OSFP 400Gb/s connector on one side and two separate QSFP56 200Gb/s connectors on the other. NADDOD breakout DAC can provide lower latency in short-distance transmission, and it is suitable for a variety of application scenarios such as data centers, high-performance computing, and storage networks, especially in environments that require rapid deployment and flexible configuration.

NADDOD provides four types of MPO-12 APC female single-mode and multi-mode elite trunk cables. NADDOD IB NDR APC fiber patch cord minimizes reflections at the fiber connection and meets the stringent optical surface requirements of IB NDR transceivers. Paired with NADDOD APC patch cords, NDR transceivers reduce signal distortion and raw physical BER is better than E-8, perfectly compatible with the InfiniBand system. NADDOD provides reliable solutions for high-quality signal transmission.

NADDOD's 200G InfiniBand HDR QSFP56 AOC is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser) active optical cable (AOC) designed for use in 200Gb/s InfiniBand HDR systems. The 200G AOC offers high port density and configurability, and a much longer reach than passive copper cables in the data centers. Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.

NADDOD's 200G InfiniBand HDR QSFP56 DAC primarily enables 200G high bandwidth links. It supports 200G Ethernet rates and InfiniBand HDR. It provides a direct connection solution from QSFP56 to QSFP56 copper cable. It is suitable for very short links and provides an affordable way to establish 200 Gigabit links across adjacent racks.

NADDOD's 200G InfiniBand HDR QSFP56 Breakout AOC Compatible QSFP56 to 2x100G QSFP56 Breakout Active Optical Cable operating over Multimode Fiber. It is compliant with IEEE 802.3, QSFP56 MSA, SFF-8024, SFF-8679, SFF-8665, SFF-8636, and InfiniBand HDR. It provides a connection of a 200G QSFP56 port on one end and two 100G QSFP56 ports on the other end, which is suitable for quick and simple connections within racks and across adjacent racks.

NADDOD's InfiniBand HDR 200G 2xQSFP56 to 2xQSFP56 active optical splitter cable (AOC) Compatible Mellanox® MFS1S90-HxxxE is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser), designed for use in 200Gb/s InfiniBand HDR (High Data Rate) systems. It provides cross-connectivity between a 200G Top of Rack (ToR) switch port configured as 2x100G ports and two 200G spine switch ports also configured as 2x100G ports. This offers a substantial CAPEX saving by reducing the required number of spine ports and cables. For data centers with more than 1600 servers, it will also save the third-layer switches.

NADDOD's 200G InfiniBand HDR QSFP56 Breakout DAC is a high-speed, cost-effective alternative to fiber optics in 200Gb/s InfiniBand HDR applications. It provides connectivity between system units with a 200Gb/s HDR QSFP56 port on one side and two 100Gb/s QSFP56 ports on the other. Rigorous cable production testing ensures the best out-of-the-box installation experience, performance, and durability.

NADDOD offers multi-mode and single-mode transceivers in QSFP56 from HDR and up to 100m, 2km. NADDOD 200G IB HDR transceivers include 200G QSFP28 SR4 and DR4, which are designed for use in 200Gb/s InfiniBand HDR systems with high performance.

NADDOD's 100G InfiniBand EDR QSFP28 AOCs are active optical fiber assemblies with QSFP28 connectors and operate over Multi-Mode Fiber (MMF). This AOC is compliant with QSFP28 MSA and RoHS-6 standards. It provides cost-efficient solutions compared to using discrete optical transceivers and optical patch cables. NADDOD 100G InfiniBand EDR QSFP28 AOCs are suitable for 100Gbps connections within racks and across adjacent racks.

NADDOD's 100G InfiniBand EDR QSFP28 DAC primarily enables 100G high bandwidth links. It supports 100G Ethernet rates and InfiniBand EDR. It provides a direct connection solution from QSFP28 to QSFP28 copper cable. It is suitable for very short links and provides an affordable way to establish 100 Gigabit links across adjacent racks.

NADDOD 100G InfiniBand EDR modules come in QSFP28 form factor shape, used over single-mode and multi-mode fiber as a media. The product portfolio comprehends 100G QSFP28 SR4, PSM4, LR4 and CWDM4. 100G QSFP28 optical modules support distance transmission from 70 meters to 10 kilometers, providing low latency and high throughput communications. It has been validated by a wide range of customers.

The ConnectX-6 smart host channel adapter (HCA) utilizes the NVIDIA Quantum InfiniBand architecture to deliver exceptional performance and NVIDIA In-Network Computing acceleration engines, enhancing efficiency in HPC, artificial intelligence, cloud, hyperscale, and storage environments.

The ConnectX-7 smart host channel adapter (HCA) offers ultra-low latency, 400Gb/s throughput, and advanced NVIDIA In-Network Computing acceleration engines for enhanced performance. It provides the scalability and robust features essential for supercomputers, artificial intelligence, and hyperscale cloud data centers.

The NVIDIA InfiniBand QM8700 Series delivers high-performance networking solutions with low latency and exceptional scalability. Designed for supercomputing and data center environments, this series enhances connectivity and efficiency for demanding applications, ensuring reliable performance in modern computing landscapes.

The NVIDIA Quantum-2-based QM9700 and QM9790 switch systems deliver an unprecedented 64 ports of NDR 400Gb/s InfiniBand per port in a 1U standard chassis design. A single switch carries an aggregated bidirectional throughput of 51.2 terabits per second (Tb/s), with a landmark of more than 66.5 billion packets per second (BPPS) capacity.

The NVIDIA Quantum-X800 Q3400-RA 4U switch, the first to leverage 200Gb/s-per-lane serializer/deserializer (SerDes) technology, significantly enhances network performance and bandwidth. NADDOD SiPh-based OSFP-1.6T-2xDR4H modules typically connect with Q3400-RA for delivering high bandwidth and low power consumption in hyperscale data centers. The NVIDIA Quantum-X800 Q3400-RA features 144 ports at 800Gb/s distributed across 72 octal small form-factor pluggable (OSFP) cages with ultra-low latency and high bandwidth for next-gen AI.
