1m (3ft) 200G QSFP56 to 2X100G QSFP56 Breakout InfiniBand HDR Active Optical Cable for Mellanox

Click to open expanded view

Global Local Service

Lifetime Technical Support

Mellanox MFS1S50-H001E/MFS1S50-H001V Compatible AOC 1m (3ft) IB HDR 200Gb/s to 2x100Gb/s QSFP56 to 2xQSFP56 Active Optical Splitter Cable (850nm, MMF, LSZH)

Name: Mellanox MFS1S50-H001E/MFS1S50-H001V Compatible AOC 1m (3ft) IB HDR 200Gb/s to 2x100Gb/s QSFP56 to 2xQSFP56 Active Optical Splitter Cable (850nm, MMF, LSZH)
Brand: Naddod
SKU: 32645
Price: 719.00 USD
Availability: InStock
Rating: 4.9 (3 reviews)

#32645

Model: Q2Q56-200G-A1H

Sold: 831

In Stock : 60

Shipping Today

$ 719

Request Free Samples

Brand:

NADDOD (InfiniBand)

HPE (InfiniBand)

NADDOD (InfiniBand)

HPE (InfiniBand)

Length:

1m (3ft)

3m (10ft)

5m (16ft)

7m (23ft)

10m (33ft)

15m (49ft)

20m (66ft)

30m (98ft)

1m (3ft)

3m (10ft)

5m (16ft)

7m (23ft)

10m (33ft)

15m (49ft)

20m (66ft)

30m (98ft)

Item Spotlights

100% compatible with NVIDIA/Mellanox InfiniBand devices, customizable for other band compatibility
Perfect alternative option for Mellanox MFS1S50-H001E/MFS1S50-H001V, beyond IBTA industry bit-error-rate (BER) standards
NVIDIA Elite Partner, global top10 manufacturer, two-thirds of global supercomputing center users choose
Save 50% + budget for GPU-accelerated computing in InfiniBand networks
Unique provider for customizing InfiniBand products in hardware

Mellanox MFS1S50-H001E/MFS1S50-H001V Compatible AOC 1m (3ft) IB HDR 200Gb/s to 2x100Gb/s QSFP56 to 2xQSFP56 Active Optical Splitter Cable (850nm, MMF, LSZH)

Free Worldwide Shipping on Orders over $ 99

Description

Connectivity Solutions

Highlights

Questions & Answers

Resources

$ 719

Description

Connectivity Solutions

Highlights

Questions & Answers

Resources

NVIDIA/Mellanox® MFS1S50-H001E/MFS1S50-H001V Compatible 1m (3ft) 200G InfiniBand HPC Active Optical Cable (QSFP56 to 2xQSFP56, OM3 MMF, Black Pulltab)

Mellanox® MFS1S50-VxxxE is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser), cost-effective 200Gb/s to 2x100Gb/s active optical splitter cable (AOC) designed for use in InfiniBand HDR and 200GbE Ethernet systems. NADDOD offers optimal Mellanox MFS1S50-H001E/MFS1S50-H001V Compatible 1m (3ft) 200G QSFP56 to 2X100G QSFP56 Breakout HDR AOC for QM8700/QM8790, MCX653106A-HDAT-SP/MCX653105A-HDAT-SP/MCX653106A-ECAT-SP/MCX653105A-ECAT-SP, it can be perfectly adapted to NVIDIA switches and NICs, providing higher transmission efficiency in supercomputers and large-scale systems with strict requirements to guarante 100% compatibility between connectors and devices, and ensure stable transmission and high reliability of the network. This active optical splitter cable complies with QSFP-MSA and 200GBASE-SR4 specifications.

Specifications

Compatible

MFS1S50-H001E/MFS1S50-H001V

Modulation Format

4x 50Gb/s PAM4

Product Type

Q2Q56-200G-A1H

Vendor Name

NADDOD

Connector Type

QSFP56 to 2xQSFP56

Max Data Rate

200Gb/s HDR to 2x100Gb/s HDR100

Minimum Bend Radius

30mm

Wavelength

850nm

Cable Length

Fire Rating Level

UL OFNR

Jacket Material

LSZH (Low Smoke Zero Halogen)

DDM

Supported

Host Require

FEC

Transmitter Type

VCSEL

Receiver Type

BER

Better Than 1E-15

Power Supply

Single 3.3V

Hot pluggable

Supported

Programmable Rx output amplitude and pre-emphasis

Supported

RoHS

LF (Lead Free) HF (Halogen Free) PCB

Power Consumption

4.35W Power Dissipation

Application

200G InfiniBand HDR high-performance data center

Commercial Temperature Range

0~70°C

Protocols

SFF-8636, SFF-8665, 200G Ethernet, RoHS, InfiniBand HDR

Connectivity Solutions

ID	Part Number	Description	Unit Price
32645	Q2Q56-200G-A1H	1m (3ft) 200G QSFP56 to 2X100G QSFP56 Breakout InfiniBand HDR Active Optical Cable for Mellanox	$ 719
32638	Q56-200G-A3H	Mellanox MFS1S00-H003E/MFS1S00-H003V Compatible 3m (10ft) 200G QSFP56 Active Optical Cable for InfiniBand QM8700, QM8790	$ 533.00
/	MQM8700-HS2F	Mellanox Quantum™ HDR InfiniBand Switch, 40 QSFP56 ports, 2 Power Supplies (AC), x86 dual core, standard depth, P2C airflow, Rail Kit	/
/	MQM8790-HS2F	Mellanox Quantum™ HDR InfiniBand Switch, 40 QSFP56 ports, 2 Power Supplies (AC), unmanaged, standard depth, P2C airflow, Rail Kit	/
/	MCX654106A-ECAT	ConnectX®-6 VPI adapter card, 100Gb/s (HDR100, EDR InfiniBand and 100GbE), dual-port QSFP56, Socket Direct 2x PCIe 3.0/4.0 x16, tall bracket	/
/	MCX653436A-HDAI	ConnectX®-6 VPI adapter card, 200Gb/s (HDR IB and 200GbE) for OCP 3.0, with host management, Dual-port QSFP56, PCIe4.0 x16, Internal Lock	/

Product Highlights

Unique provider for customizing in hardware

Why NADDOD IB products？

NADDOD's 200G InfiniBand HDR AOC provides the same solution as NVIDIA/Mellanox, getting 120% of the performance at 50% of the price of the original. Bandwidth tests and latency tests in HDR network environment are verified by NVIDIA/Mellanox equipment connection, and the practical cases of supercomputing application solutions associated with InfiniBand products of NADDOD service are verified to be fully comparable to the performance and quality of the original.

NADDOD HPC solutions accelerate global network progress

NADDOD continuously achieves efficient integration with NVIDIA products and solutions in cloud computing, artificial intelligence, HPC, and other areas. In data-intensive applications, NADDOD's high-performance networking products have been deployed to the core of national well-known supercomputing centers in January 2022, and the solutions include high-performance switches, optical connectors and NICs to support renowned supercomputing centers and undertake various large-scale scientific and engineering computing tasks with high-performance networking.

Quality Certification

What We Supply

Questions & Answers

Where can I download FW for QM8700 IB switch?

QM8700 do not have FW file. Because managed systems do not require Firmware updating. Firmware updating is done through the MLNX-OS management software. You can download the firmware updating file in the Resources section of the QM8790 listing, or click here for other QM87XX series switches firmware updating user manual.

If hypothetically we had a problem where we don’t know if the issue is with the NADDOD cables or with the Mellanox switches, or maybe Mellanox switch failure due to cable's problem, would you provide us technical support？

Of course. No matter what problem you have, you can just contact us directly. NADDOD will provide technical support: including switch and network configuration services to help you find out and solve problems.And please make sure: AOC/DAC cables or transceivers are networking interconnection accessories, which essentially are just a connection of signal transmission and don't cause any hardware or software problems to the original devices. NADDOD Test Center recreates a 100% original environment for testing all parts of our IB products to provide customers the highest quality and performance.

Whether the InfiniBand cables MFS1S50-H001E can be used on Ethernet switches?

Yes, InfiniBand cables MFS1S50-H001E can be used for both IB and Ethernet, but Ethernet cables can only be used for Ethernet. NADDOD provides both high cost-effective IB and Ethernet cables for your options.

Is there any 200G 1m IB breakout AOC MFS1S50-H001E in stock?

Yes, of course, you can check the stock info below the product title. Our 1m-30m 200G IB cables are in large stock, which support same-day shipping after passing full test process. For other meters not shown, you can click contact us/quote/need help for inquiry. As you may know, the lead time of NVIDIA original IB cables MFS1S50-H001E is 6 to 8 weeks, while NADDOD can support ship within 1 week and even for your special customized requirements, our lead time is only 2 weeks.

Could you please provide two real pictures of a 10m 200G EDR AOC for me, with the outer label showing the length 10m?

Okay, please check the picture below. The outer jacket materials of all our InfiniBand cables are LSZH (Low Smoke Zero Halogen) and certified by UL OFNR (fire rating level). Our cable levels are the same as NVIDIA Mellanox LinkX InfiniBand Cables MFS1S50-H001E.

We have some QM8700 200G switches connected with the original IB cables MFS1S50-H001E , whether there'll be any incompatibility problem if we use them with your cables?

NADDOD IB cables are perfect alternative option for Mellanox MFS1S50-H001E, beyond IBTA industry bit-error-rate (BER) standards. We can provide the technical test report for your specified original device environment. You can also check our practical cases/solutions, which had proved that our IB products can reach even exceed the performance and quality of the originals.

Are InfiniBand cables generally referred to AOC?

No, there are two kinds of InfiniBand cables: DAC(copper) and AOC (optical). NADDOD can provide InfiniBand FDR, EDR, HDR DAC, and AOC cables at super affordable prices and large stock.

What's the difference between QM8700 and QM8790 switches? Whether there is a difference in the selection of the cables?

There is no difference in function and performance between QM8700 and QM8790. QM8700 is managed, and QM8790 is unmanaged (out-of-band management). NADDOD can provide 200G IB AOC and DAC cables that can be used with the two switches.
