NVIDIA/Mellanox MCP7Y00-N01A Compatible DAC 1.5m (5ft) Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP InfiniBand NDR Passive Copper Splitter Cable

#101514
#101514
Model: O2O112-800G-CU1-5H
Brand:
NADDOD (InfiniBand)
NADDOD (InfiniBand)
request-free-sample
Request Sample

Item Spotlights

  • 100% verified by the original, perfectly compatible with NVIDIA QM9700/9790 devices.
  • Tested for compatibility with multiple firmware versions, compliant with IBTA Industrial BER standards.
  • Free test environment and samples are available to experience the high-quality product performance.
  • Complies with OSFP MSA, CMIS 5.0, and RoHS protocols, providing a reliable and sustainable solution.
  • 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.
NVIDIA/Mellanox MCP7Y00-N01A Compatible DAC 1.5m (5ft) Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP InfiniBand NDR Passive Copper Splitter Cable
NVIDIA/Mellanox MCP7Y00-N01A Compatible DAC 1.5m (5ft) Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP InfiniBand NDR Passive Copper Splitter Cable
Specifications
Applications
Product Highlights
Questions & Answers
Customer Reviews
Resources
Specifications
Applications
Product Highlights
Questions & Answers
Customer Reviews
Resources
Description

NVIDIA/Mellanox MCP7Y00-N01A Compatible 1.5m (5ft) Twin-port 2x400Gb/s OSFP to 2x400Gb/s OSFP Passive Copper Splitter Cable

NADDOD O2O112-800G-CU1-5H is an 800Gb/s twin-port OSFP (Octal Small Form-factor Pluggable) to 2x400Gb/s OSFP passive Direct Attach Copper (DAC) dual breakout (aka splitter) cable for 400Gb/s End-to-End Infiniband solutions. DAC cables are the lowest-cost, lowest-latency, near zero power consuming, high-speed links available due to their simplicity of design and minimal components. Main use is linking an 800Gb/s Quantum-2 switch to OSFP-based 400Gb/s ConnectX-7 PCIe network adapter cards. NADDOD’s cable solutions provide power-efficient connectivity enabling higher port bandwidth, density and configurability at a low cost and reduced power requirement in the data centers.

Specifications
Compatible
MCP7Y00-N01A
Vendor Name
NADDOD
Product Type
O2OSFP-800G-CU1-5H
Max Data Rate
800Gb/s to 2x400Gb/s
Connector Type
OSFP to 2xOSFP
Modulation Format
100Gb/s PAM4
Minimum Bend Radius
10x OD
Wire AWG
28AWG
Cable Length
1.5m
Jacket Material
polyvinylchloride (PVC)
Hot pluggable
Supported
Power Supply
Single 3.3V
Power Consumption
<0.1W
Application
Quantum-2 InfiniBand switch to two 400Gb/s ConnectX-7 OSFP adapters
Commercial Temperature Range
0~70°C
Protocols
SFF8024, OSFP MSA, CMIS 5.0, RoHS
Applications
Product Highlights
Why NADDOD
  • Module Availability
    Worry-Free - Rigorous authentic testing!
  • Multi-version Device Compatibility
    Multi-Version - Easy adaptation for each module!
  • High-Performance
    Actual Test Data-Better results intuitively!
Our Approach
Test scene
Test scene
NADDOD stringently selects a series of items in a professional testing environment to ensure the perfect blend of product performance andreliability. Including hardware compatibility (plugging, unplugging, rebooting), software compatibility (connectivity, parameters) and performance testing (DDM, BER, stability).
Test result
QM 9700 Version:3.11.1002
MCX75310AAS-NEAT version:28.37.1014
  • Multi-Version
    Switch Side Testing
    NIC Side Testing
    Multi-Version  Testing
    No matter the device version, the optical modules are rigorously tested to ensure seamless integration with various hardware andsoftware versions.
  • Connectivity
    Switch Side Testing
    NIC Side Testing
    Connectivity  Testing
    The module can connect to both devices normally, and the device port status is up.
  • BER
    Switch Side Testing
    NIC Side Testing
    BER  Testing
    Tests REAL-TIME BER to ensure the accuracy of data transmission under high load conditions.
Test result
Test result
Test result
Test result
Test result
Test result
Questions & Answers
Ask a Question
Q:
I only use the 1st splitter of the splitter IB cable, the 2nd splitter is not installed on the NIC, will it affect the use of the 1st splitter cable?
A:
It has no effect after the port is configured with a split port, it is recognized as two logical ports inside the device, and each splitter corresponds to one logical port, which has no effect on each other.
Q:
Why are there no NDR AOCs?
A:
OSFPs are very large and heavy and the fiber breaks easily. A two-splitter cable will have three large transceiver ends. A four-splitter cable will have five transceivers. That would almost certainly make it easy to break the fiber during installation - especially for a 30 meter AOC.
Q:
What is the maximum transmission distance of the O2O112-800G-DACH cable?
A:
The maximum distance the passive DAC can provide is 2M.
