100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco

Click to open expanded view

100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
Global Local Service
Lifetime Technical Support

Cisco Compatible 100GBASE-ER QSFP28 Single Lambda 1310nm 30km DOM Duplex LC Optical Transceiver Module for SMF

#14278
#14278
Model: QSFP-100G-ER
  Sold:  138
 In Stock :  205
  Shipping Today
$ 1999.00
Brand:
Cisco
Arista
Juniper
Intel
HW
H3C
Generic
NVIDIA/Mellanox (Ethernet)
Cisco
Arista
Juniper
Intel
HW
H3C
Generic
NVIDIA/Mellanox (Ethernet)
request-free-sample
Request Free Sample

Item Spotlights

  • Max Power Consumption 5.5W.
  • Provide Professional Compatibility and Parameter Test Reports.
  • Hot Pluggable QSFP28 and 100G Single Lambda MSA Compliant, 1310nm PAM4 modulated.
  • Class 1 FDA Laser Safety, Compliant with RoHS Environmental Protection Standards (Lead-Free).
  • DDM(Digital Diagnostic Monitoring) Supported.
  • Single Lane Data Path Aligned with Future Single-lane 100G Ports (SFP112).
  • 30-Day Free Return, 3-Year Free Exchange, 3-Year Warranty, Lifetime After-sales Technical Support.
100GBASE-ER QSFP28 Single Lambda 1310nm 30km SMF Module for Cisco
Cisco Compatible 100GBASE-ER QSFP28 Single Lambda 1310nm 30km DOM Duplex LC Optical Transceiver Module for SMF
NADDOD
NADDOD
Free Worldwide Shipping on Orders over $ 99

$ 1999.00

Features
Specifications
Applications
Questions & Answers
Customer Reviews
Features
Specifications
Applications
Questions & Answers
Customer Reviews
Product Highlights
Application of NADDOD QSFP-100G-ER transceiver

Applicable to 100G data center interconnection, campus network, telecommunications field, and cloud computing, etc.

Application of NADDOD QSFP-100G-ER transceiver
Six professional transceiver performance tests

NADDOD has a full range of professional testing equipments for testing various parameters of products to ensure high performance and quality of optical transmission stability.

Six professional transceiver performance tests
Standardized Service
Standardized Service
Compare Items
QSFP-100G-ER

QSFP-100G-ER
QSFP-100G-SR4

QSFP-100G-SR4
QSFP-100G-PSM4

QSFP-100G-PSM4
QSFP-100G-LR4

QSFP-100G-LR4
QSFP-100G-ZR4

QSFP-100G-ZR4
Wavelength
1310nm
850nm
1310nm
1310nm
1310nm
Transmission Distance
30km（no FEC）40km（FEC）
70m(@OM3)/(100m@OM4)
2km
10km
80km（FEC）
Media
SMF
MMF
SMF
SMF
SMF
TX Power
-2.9~4.5dBm
-8.4~2.4dBm
-5.5~2dBm
-2.9~4.5dBm
2.0~4.5dBm
Typical Power Consumption
≤4.5W
≤3.5W
≤3.5W
≤3.5W
≤6.5W
Commercial Temperature Range
0~70°C
0~70°C
0~70°C
0~70°C
0~70°C
Top OEMs
NADDOD
NADDOD
NADDOD
NADDOD
NADDOD
NADDOD optical transceivers/DAC/AOC are compatible with over 140+ well-known brands of networking equipment on the market, such as Cisco, Juniper, Arista, and H3C.
NADDOD has set up a series of testing procedures to ensure the compatibility of optical transceivers, including TX/RX signal quality testing, reliability and stability testing, transmission rate and protocol testing, and spectral evaluation testing. Apart from this, we have a professional laboratory testing center to ensure that all optical transceivers are tested on real machines.
What We Supply
research-and-development
testing
quality
production
Specifications
Product Type
QSFP-100G-ER
Vendor Name
NADDOD
Form Factor
QSFP28
Max Data Rate
103.125Gbps
Wavelength
1310nm
Transmission Distance
30km
Connector
Duplex LC
Media
SMF
Transmitter Type
EML
Receiver Type
APD
TX Power
-2.9~4.5dBm
Receiver Sensitivity
< -16.65dBm(BER = 1x10-12)/< -20.5dBm(BER = 5x10-5)
Typical Power Consumption
≤4.5W
Commercial Temperature Range
0~70°C
DDM
Supported
EMC ( Magnetic Compatibility)
Supported
Modulation Mode
NRZ
CDR
TX & RX Built-in CDR
Protocols
CEI-28G-VSR, QSFP28 MSA, SFF-8636
Compatible
Cisco, Arista, Juniper, Dell, Mellanox, Generic
Compatible Part Number
QSFP-100G-ER-SM1310, QSFP-100G-ERL-WDM1300
